Description
Side discharge
150 gal./min capacity
Solids handling capability up to 2"
Automatic non-mercury float switch
Rated for continuous use
Request a Quote
Honda WSP100
Thank you!
Your quote request has been received. We'll be in touch shortly.
Specifications
Specifications
Pump Type Submersible Trash pump
Starting Type Automatic
Casing Stainless Steel
Motor (HP) 1
Voltage 115
Starting amps 47
Running amps 11.1
Duty Continuous
Motor insulation Class F
Overhead protection Built-In Thermal Automatic Reset
Discharge Type Side
Discharge capacity 150 gpm
Max. head (feet) 42
Port diameter ( inches) 2.0 FNPT
Maximum pressure 18 psi
Solids handling 2.0"
Impeller Single Channel Stainless Steel
Seals Tandem Mechanical Carbon/Ceramic-upper SIC/SIC-lower
Cord length (feet) 25
Cord type Heavy-Duty 115V
Dimensions (WxH) 9.0" x 22.8"
Pump diameter 9.0"
Dry weight 41 lbs.
Residential Warranty 1 year
Commercial Warranty 1 year
